Product Introduction
1. Coupled with superior quality alternator.
2. Powered by easy-to-start single cylinder gasoline engine (YAMAHA, HONDA, KOHLER, Briggs&Stratton engine for optional)
3. Low oil alert, shuts down engine automatically when low oil is detected.
4. Circuit breaker, cuts off electricity system when overload.
5.New air cleaner, small unique design, exhausted oil gas combusted in carburetor for the second time through a special designed pipe, free from oozing.
6. Muffler with spark arrestor, lower noise and more environment friendly.
7. AVR(automatic voltage regulator), stabilizes the output power.
8.Portable compact safe design with open rugged durable durable frame, easy to operate.
9.Perfect performance with stable running up to 12.5 hours at 50% load, for home or commercial use.
10. EPA, CARB, CE, etc. Certificates approved.
Main Parameter
home use generator | CG2500 | CG3000 | GG3500 | GG4500E | GG5500E | GG6500E |
AC frequency(HZ) | 50/60 | 50/60 | 50/60 | 50/60 | 50/60 | 50/60 |
Cont.AC output(kw) | 2 | 2.5 | 3 | 4 | 5 | 6 |
Max.AC output(kw) | 2.5 | 3 | 3.5 | 4.5 | 5.5 | 6.5 |
Type | Brushless,self-exciting,2-poles,single phase |
AC output Voltage(V) | 120,220,230,240,110/220,120/240 |
DC output(V/A) | 12/8.3 |
Insulation | F |
Power factor(cosf) | 1 |
Model | 168F | 168F | 178F | 188F | 188F | 188F |
Type | OHV single-cylinder 4-stroke air-cooled |
Displacement(cc) | 196 | 196 | 270 | 389 | 389 | 389 |
Engine Speed(rpm) | 3000 | 3000 | 3000 | 3000 | 3000 | 3000 |
Starting System | Recoil or Recoil/Electric |
Max.power Output(hp) | 5.5 | 6.5 | 9 | 11 | 11 | 13 |
Fuel Tank capacity(L) | 15 | 15 | 25 | 25 | 25 | 25 |
Oil capacity | 0.6L | 0.6L | 1.1L | 1.1L | 1.1L | 1.1L |
lgnition system | T.C.I | T.C.I | T.C.I | T.C.I | T.C.I | T.C.I |
DIM(L×W×H)(mm) | 615×455×455 | 615×455x455 | 700×530×560 | 700×530×560 | 700×530×560 | 700×530×560 |
Net weight(kg) | 45 | 46 | 70 | 80 | 85 | 90 |
